Device parameters and interfaces
Leuze electronic BPS 34 63
TNT 35/7-24V
Note!
The events of the switch-on function and switch-off function are both linked to one another
with a logical OR.
Hex coding of module 8 "Switching output"
The value listed in the table shows the hex coding of the default settings.
Input data
None
Output data
Switch-off
function
[AF]
The parameter specifies the
events which reset the switching
output:
- speed valid
- speed not valid
- position limit value 1 reached
- position limit value 1 not
reached
- outside measurement range
- within measurement range
- position limit value 2 reached
- position limit value 2 not
reached
- erroneous measurement
- successful measurement
- PROFIBUS pos. edge
- PROFIBUS neg. edge
- speed limit value reached
- speed limit value not reached
6.0
6.1
6.2
6.3
6.4
6.5
6.6
6.7
7.2
7.3
7.4
7.5
7.6
7.7
Bits
For each
0: Not active
1: Active
0
0
0
0
0
0
0
0
0
1
0
0
0
0
–
22
22
14 + 16
14 + 16
10
10
15 + 17
15 + 17
1 + 9
1 + 9
8
8
25
25
Parameter length: 8 byte
e
Internal address of module 8 Bias level address 0 Selection of the speed limit value address 1 Pulse duration address 2 Switch-on function address 4 Switch-off function address 6
02 00 00 01 90 04 00 08 00
Output
data
Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Switching
output
PROFIBUS
edge
This bit can be used to operate
the switching output if the "PRO-
FIBUS edge" function is config-
ured.
0.0 Bit
0 -> 1: Positive edge
1 -> 0: Negative edge
0 ––
Output data length: 1 byte
