Device parameters and interfaces
64 BPS 34 Leuze electronic
Note!
With the "PROFIBUS edge" function, the switching output can be directly activated or deac-
tivated by setting bit 0.0.
8.1.7.9 Module 9: Control
Description
The Control module manages timing of the position calculation by starting and stopping the
decoding. Control is performed depending on certain events such as the switching input,
time functions or PROFIBUS output bits. Using parameters, the events which influence the
states are determined.
Parameters
Hex coding of module 9 "Control"
The value listed in the table shows the hex coding of the default settings.
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Measure-
ment start
mode
The start mode determines by
which event the position mea-
surement is started.
0
unsign
8
0: Deactivated
1: After initialization
2: Following event:
Switching input or start event
by setting output bit 0.0
1 –7g
Measure-
ment stop
mode
The measurement stop mode
determines after which event
the position measurement is
stopped.
1
unsign
8
0: No function
1: After valid measurement
result
2: After timeout (stop
timeout)
3: After timeout with
re-trigger (stop timeout) by
setting output bit 0.0 or by
the switching input
4: By stop event or by set-
ting output bit 0.1 or by the
switching input (the switching
input must be programmed
for this purpose)
5: By errors
4 –7g
Stop time-
out in [ms]
Time for stop timeout 2
unsign
16
0 … 65,535 10,000 ms –
Parameter length: 4 byte
