Device parameters and interfaces
70 BPS 34 Leuze electronic
8.1.7.13 Module 12: Status
Note!
Underlined in the CR column are the modules which must be activated in addition to the cur-
rent module.
Description
This module supplies various BPS 34 status information to the PROFIBUS master.
Parameters
None
Input data
Output data
None
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Measure-
ment error
Indicates that no valid integration
value could be determined (mea-
surement value preparation mod-
ule).
0.0 Bit
0: OK
1: Error
0 ––
Range sta-
tus
Indicates that the measurement
range has been exceeded (mea-
surement value acquisition mod-
ule)
0.1 Bit
0: OK, within measure-
ment range
1: Measurement range
exceeded
0 –10
Preset
active
Indicates a position value output
with active static preset or
dynamic preset (Preset module)
0.2 Bit
0: No preset active
1: Preset active
0 –
3a
4c
Preset
teach
Toggle bit, changes during the
teach event for the static and
dynamic preset value (Preset
module)
0.3 Bit 0.1: Dyn. preset teach 0 –
3a
4c
Position
limit value
status 1
(static or
dynamic)
Indicates that limit value 1 has
been exceeded (Measurement
value monitoring module).
0.4 Bit
0: No limit value violation
1: Value greater than limit
0 –
14d
16d
Position
limit value
status 2
(static or
dynamic)
Indicates that limit value 2 has
been exceeded (Measurement
value monitoring module).
0.5 Bit
0: No limit value violation
1: Value greater than limit
0 –
15d
17d
Standby
status
Signals the standby status (Con-
trol module)
0.7 Bit
0: BPS active
1: BPS in standby mode
0 –9d
Input data length: 1 byte
