Device parameters and interfaces
Leuze electronic BPS 34 79
TNT 35/7-24V
Note!
The preset function (module 3) must be retaught following a reset.
8.1.7.21 Module 20: Speed
Note!
Underlined in the CR column are the modules which must be activated in addition to the cur-
rent module.
Description
Outputs the current speed with the configured resolution and the desired scaling factor. In
order for the speed to be calculated in the BPS 34 and output in this module, module 22
(Control speed measurement) must also be activated in the PROFIBUS project.
Parameters
None
Input data
Note!
The scaling of the position value has no effect on the scaling or output of the speed.
The direction of movement of the BPS 34 is displayed in module 23 "Speed measurement
status" (see Page 84) under "Direction of movement".
Output data
None
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Speed
Current speed 0
unsign
32
0 … 10,000,000 0 Scaled 22
Input data length: 4 byte
