Device parameters and interfaces
86 BPS 34 Leuze electronic
8.1.7.25 Module 24: Min./max. speed
Description
The min./max. speed function monitors the speed value and transfers the maximum and
minimum value to the PROFIBUS master. Recording can be controlled via module 22
"Speed measurement control". It is also possible to reset values to the initialization value via
module 22.
Parameters
None
Input data
Output data
None
Input data Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Min. speed
Minimum speed for detected
period.
0
unsign
32
0 … 10,000,000 0 Scaled
22
Max. speed
Maximum speed for detected
period.
4
unsign
32
0 … 10,000,000 0 Scaled
Input data length: 8 byte
