8.1.7.26 Module 25: Dynamic speed limit value
Note!
Underlined in the CR column are the modules which must be activated in addition to the cur-
rent module.
Description
The limit value function compares the current speed with a limit speed stored in the config-
uration. This occurs in the range defined by the range start and end. If a direction-dependent
limit value check is activated via the direction selection parameter, the values of range start
and range end define the direction. The check is always performed from range start to range
end. For example, if the range start is "5500" and the range end is "5000", the direction-
dependent check is only performed in the direction from "5500" to "5000". If the check is
independent of direction, the order of range start and end is without meaning. If the value is
above or below the limit value, the limit value status in module 23 is set and, if configured,
the switching output is appropriately set.
Parameters
Parameter Description Rel.
addr.
Data
type
Value range Default Unit CR to
module
Speed limit
value mode
Parameter activates or deacti-
vates limit value check for
Speed limit value 1,
Speed limit value 2,
Speed limit value 3,
Speed limit value 4
.
0.0
0.1
0.2
0.3
Bits
For each limit value
0: Limit value not active
1: Limit value activated
0
0
0
0
–
8b
22
Direction
selection
Selection of direction-dependent
or direction-independent limit
value check for
Speed limit value 1,
Speed limit value 2,
Speed limit value 3,
Speed limit value 4
0.4
0.5
0.6
0.7
Bits
For each limit value
0: Check in both direc-
tions
1: Only check in
one direction
0
0
0
0
–
Switching
type
Condition for the signal change
of the switching output and the
status bits for
Speed limit value 1,
Speed limit value 2,
Speed limit value 3,
Speed limit value 4
1.0
1.1
1.2
1.3
Bits
For each limit value
0: Value greater than limit
1: Value less than limit
0
0
0
0
–
Speed limit
value 1 in
[mm/s]
Limit value is compared to the
current speed.
2
unsign
16
0 … 20,000 0 mm/s
23b
Speed hys-
teresis 1 in
[mm/s]
Relative offset of the switching
point.
4
unsign
16
0 … 20,000 0 mm/s
a
b
c
d
e
