Device parameters and interfaces
88 BPS 34 Leuze electronic
Range
start limit
value 1 in
[mm]
The speed limit value is moni-
tored starting from this position.
6 sign32 -10,000,000 … 10,000,000 0 mm
23b
Range end
limit value
1 in [mm]
The speed limit value is moni-
tored up to this position.
10 sign32 -10,000,000 … 10,000,000 0 mm
Speed limit
value 2 in
[mm/s]
Limit value is compared to the
current speed.
14
unsign
16
0 … 20,000 0 mm/s
23c
Speed hys-
teresis 2 in
[mm/s]
Relative offset of the switching
point.
16
unsign
16
0 … 20,000 0 mm/s
Range
start limit
value 2 in
[mm]
The speed limit value is moni-
tored starting from this position.
18 sign32 -10,000,000 … 10,000,000 0 mm
Range end
limit value
2 in [mm]
The speed limit value is moni-
tored up to this position.
22 sign32 -10,000,000 … 10,000,000 0 mm
Speed limit
value 3 in
[mm/s]
Limit value is compared to the
current speed.
26
unsign
16
0 … 20,000 0 mm/s
23d
Speed hys-
teresis 3 in
[mm/s]
Relative offset of the switching
point.
28
unsign
16
0 … 20,000 0 mm/s
Range
start limit
value 3 in
[mm]
The speed limit value is moni-
tored starting from this position.
30 sign32 -10,000,000 … 10,000,000 0 mm
Range end
limit value
3 in [mm]
The speed limit value is moni-
tored up to this position.
34 sign32 -10,000,000 … 10,000,000 0 mm
Speed limit
value 4 in
[mm/s]
Limit value is compared to the
current speed.
38
unsign
16
0 … 20,000 0 mm/s
23e
Speed hys-
teresis 4 in
[mm/s]
Relative offset of the switching
point.
40
unsign
16
0 … 20,000 0 mm/s
Range
start limit
value 4 in
[mm]
The speed limit value is moni-
tored starting from this position.
42 sign32 -10,000,000 … 10,000,000 0 mm
23e
Range end
limit value
4 in [mm]
The speed limit value is moni-
tored up to this position.
46 sign32 -10,000,000 … 10,000,000 0 mm
