User Manual for PuraLev
®
600SU
www.levitronix.com
PL-4032-00, Rev06, DCO# 20-144
5
System Name
Article #
Pump Head
Socket
Motor
Controller
Note
PLD-600SU.1
100-90654
PHS-600.1
LPM-600.5
LPC-600.1-01
Adaptor/Extension (0.5 - 10m) cables according to Table 3 (Position 4a and
4b) have to be ordered as separate article with specified length.
ATEX Cable Sealing System can be ordered according to Table 4.
PLD-600SU.2
100-90655
LPM-600.5
LPC-600.2-01
PLD-600SU.4
100-90657
LPM-600.4
LPC-600.1-01
PLD-600SU.5
100-90658
LPM-600.4
LPC-600.2-01
Table 1: Standard system configurations with motor controller and pump head socket
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
1a
1b
Single-Use (SU)
Pump Heads
DCP-600.2
DCP-600.2-G25
(Gamma Irradiated with
Dosage ≥ 25 kGy)
100-90784
100-91079
Impeller / Pump Housing
Sealing Ring
In-/Outlet Fittings
Polypropylene (FDA, USP Class VI, BSE/TSE/Animal free)
Silicon (FDA, USP Class VI, BSE/TSE/Animal free)
(ASME BPE 2009)
Max. Flow
Max. Diff.-Pressure
Max. Viscosity
75 liters/min / 20 gallons/min
3.1 bar / 45 psi
50 cP (preliminary information)
Wet Pump Vol./Surface
113 ml / 370 cm
2
Max. Liquid Temp.
60°C / 140°F
1c
SU Pump Head
with Sterile
Fittings
DCP-600.2-SF1-G25
100-91294
Pump (A) / Adaptor (C)
Sterile Fittings (B)
Fitting Compatibility
Applied Gamma Dosage
DCP-600.2 / Triclamp reducer in Polypropylene
AseptiQuik
®
X from CPC
®
with part # AQX33024
1
Various types including autoclavable versions available at CPC
®
≥ 25 kGy
2a
Motor
(ATEX / IECEx)
LPM-600.5
100-10039
Housing
Epoxy (anti-corrosive) coated Aluminum (IP67)
Cable / Connectors
2x 3m cables with PVC jacket / 2x circular (M23, IP-67)
ATEX / IECEx Marking
II 3G Ex nA IIC T5 Gc
II 3D Ex tc IIIC T100°C Dc
2b
Motor
(ATEX / IECEx)
LPM-600.4
100-10038
Housing
- ETFE (chemical resistant) coated Aluminum
- waterproofed (IP67)
Cable / Connectors
2x 3m cables with FEP jacket / 2x circular (M23, IP-67)
3
Pump Head
Socket
PHS-600.1
100-90696
Mounting Type
Bayonet type with locking pin
Material
Anodized Aluminum
Assembly Screws
4pcs M6x16 mm (Stainless Steel)
4a
Standalone
Controller
(User Panel)
LPC-600.1-01
100-30039
(Power supply
cable and Enable
connector incl.)
Voltage / Power
48V DC / 600 W
Housing Protection
IP20
Interfaces for
Standalone Controller
Panel to set speed (automatic storage on internal EEPROM)
PLC with
1x analog  4 - 20 mA
 0 - 24 V (optocoupler)
 0 - 24 V (relais)
Standard Firmware
D9.25
4b
Extended
Controller
(PLC and USB)
LPC-600.2-01
100-30040
(Power supply
cable and PLC
connector incl.)
Interfaces for
Extended Controller
PLC with
- up to 4 digital inputs 0 - 24V (optocoupler)
- up to 4 digital outputs 0 - 24 V (relais)
- up to 2 analog inputs 4 - 20mA
- up to 2 analog inputs 0  10 V
- up to 2 analog outputs 0  5 V
USB interface (for service and system monitoring)
Standard Firmware
D9.48
Table 2: Specification of standard components (Note 1: CPC
®
and AseptiQuik
®
are registered marks of the Colder Product Company)
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
5a
Extension Adaptor
Cable for Sensors
MCAS-600.2-05 (0.5m)
MCAS-600.2-30 (3m)
MCAS-600.2-50 (5m)
MCAS-600.2-70 (7m)
MCAS-600.2-100 (10m)
190-10226
190-10238
190-10127
190-10105
190-10239
Jacket Material
Connectors
PVC
Circular Wallmountable, Metallic (IP-67) to D-SUB
5b
Extension Adaptor
Cable for Power
MCAP-600.2-05
MCAP-600.2-30
MCAP-600.2-50
MCAP-600.2-70
MCAP-600.2-100
190-10227
190-10240
190-10126
190-10106
190-10241
Jacket Material
Connectors
PVC
Circular Wallmountable, Metallic (IP-67) to COMBICON
Table 3: Specification of adaptor/extension cables
Pos.
Component
Article Name
Article #
Characteristics
Value / Feature
6a
6b
Air Cooling Module
ACM-600.2
ACM-600.3 (for ATEX)
Material / Connection Port
Air Pressure
a) PP (+ 40% Talkum) b) PP EL-
~1 - 3 bar (14  43 psi)
7a
Fan Cooling Module
FCM-600.1
190-10401
Housing / Cable Spec.
Supply Spec. / IP Rating
PP (20% Talkum) / PP jacket, 3m, circ. sealed M12 connector (PP).
24 VDC, 3.4 W / IP-65 (fan is IP68 rated).
7b
Fan Cool. Module Cable
FCC-1.1-50 (5 m)
FCC-1.1-100 (10 m)
190-10407
190-10408
Specification
PP cable jacket with circular M12 connector (PP) to open wires
8
(A-F)
ATEX Cable
Sealing System
ACS-A.1
(Roxtec)
100-90292
Sleeve (A) and Gasket (B)
Frame (C)
2x Cable Module (D)
Stainless Steel and EPDM
Roxylon (EPDM rubber)
Roxylon (EPDM rubber)
Note:
Lubricant (E) and measurement
plates (F) are included.
9
AC/DC Power Supply
TSP 600-148-M
(M = Modified Levitronix
design from Traco)
100-40013
(Traco ID Number:
T1068-01A)
Voltage / Power Output
Voltage Input
48 VDC / 600 W
85  265 VAC (automatic detection)
Certification or Standards
CB, UL, CSA, Semi F47
Table 4: Specification of accessories
