Lexicon
7-4
MPX G2 User Guide
Lo ± 5dB Low frequency boost/cut
Mid ±5dB Mid frequency boost/cut
Hi 0-5dB High frequency boost
Drive 0-40 Amount of overdrive
Tone 0-25 High frequency roll-off
Level 0dB to 64dB Output level
Screamer
Screamer is an analog model
of a vintage Tube Screamer over-
drive (powered by a fresh carbon-
zinc battery). Care has been taken
to make the behavior of this effect
accurate both sonically and elec-
tronically. The ranges of Drive and
Tone match those of the vintage
effect and it will push your amp into
high gear just like the original.
We’ve also added Lo, Mid and Hi
tone controls. For truly authentic
sounds, leave them set flat (zero),
but feel free to dial in some addi-
tional colors unobtainable with the
original.
0 190
* = Interpolated; ( ) = Option of preceding parameter
