5-3
System Controls
The MPX G2 provides a memory protection feature to prevent accidental
overwriting of your stored programs. When this control is set to On, attempting
to store a program will cause the Store process to abort, and an error message
to be displayed. To enable the Store function, select Off. (This is the default
setting.)
Option: StorePrompt
To have the MPX G2 warn you whenever loading a new program would erase
changes you have made but have not saved, press Options and set
StorePrompt to On.
This control allows you to adjust the brightness of the alphanumeric display
along a range of 0-15.
The setting of Sleep mode determines the behavior of the MPX G2 when it is left
idle. When it is on, a set of messages is cycled across the display. Like a
computer screen saver, any activity on any panel control will automatically return
the MPX G2 to normal operation. When shipped, Sleep is set to Off. You can
change this mode to display general Help messages.
The Post Bypass parameter allows you to determine the behavior of the MPX
G2's post gain effects when the front panel Bypass button is pressed. When the
Bypass button is pressed, it will light and a message will be briefly displayed to
indicate that Bypass is on. Pressing Bypass again will briefly display the
message that Bypass is off, and turn the button light off.
The choices available from the Post Bypass Mode menu are:
Bypass: Completely bypasses the post gain effects, passing
unprocessed audio directly through to the outputs.
(This is the default setting.)
All Mute: Mutes both the input and the output signal, giving
complete silence.
Input Mute: Mutes the input to the post gain effects, allowing the tail
of the effect to ring out.
Disabled: Post gain effects are not changed when Bypass is
pressed.
Memory Protect
Press Options to
set StorePrompt
Brightness
On or Off. Press Options
again to exit.
Sleep
Post Bypass
