Lexicon MPX G2 User Guide

Lexicon
7-40
MPX G2 User Guide
Mix 0-100% Dry/Wet ratio
Level Off, -89 to +6dB Amount of effect in the processed signal
Gain (1-4) -72 to +24dB Boost/cut gain of filter(s)
Fc (1-4) 20-20000Hz Center or corner frequency of filter(s)
Q (1-4) 0.1-10.0 Q of filter(s)
Mode (1-4) LShlf, Band, HShlf Determines EQ type(s)
Mix 0-100% Dry/Wet ratio
Level Off, -89 to +6dB Amount of effect in the processed signal
Gain (1-2) -72 to +24dB Boost/cut gain of filter(s)
Fc (1-2) 20-20000Hz Center or corner frequency of filter(s)
Q (1-2) 0.1-10.0 Q of filter(s)
Mode (1-2) LShlf, Band, HShlf Determines EQ type(s)
1-Band (M), 2-Band (M), 3-Band (M) and 4-Band (M)
1-Band (S), and 2-Band (S)
The 1-Band (M) effect provides
a single band of double-precision
parametric EQ.
2-Band (M), 3-Band (M) and 4-
Band (M) have two, three and four
bands, respectively, of double-pre-
cision parametric EQ. Each effect
has adjustable center frequency,
Q, boost/cut and filter type (low
shelf, band, high shelf).
1-Band (S) has two bands of
double-precision parametric EQ,
one on each channel. 2-Band (S)
has four bands of double-preci-
sion parametric EQ, two on each
channel.
The two channels share the fil-
ter controls. Center frequency, Q,
boost/cut and filter type (low shelf,
band, high shelf) are adjustable.
50 190
1-Band (M)
70 190
2-Band (M)
90 190
3-Band (M)
110 190
4-Band (M)
68 190
1-Band (S)
109 190
2-Band (S)
* = Interpolated; ( ) = Option of preceding parameter
