7-25
The Effects and Parameters
Mix 0-100% Dry/Wet ratio
Level* Off, -89 to +6dB Amount of effect in the processed signal
Rate1 0-50Hz or Left Mod and Pan rate or period ratio
1:24-24:1 cycles/beat
(Rate 1 Units) Selects frequency or cycles/beat
PW 1 0-100% Left Mod and Pan pulse width
Sync1 -120° to +120° Phase difference between left LFO Mod and Pan
Dpth1* 0-100% Left Mod and Pan depth
Rate2 0-50Hz or Right Mod and Pan rate or period ratio
1:24-24:1 cycles/beat
(Rate 2 Units) Selects frequency or cycles/beat
PW 2 0-100% Right Mod and Pan pulse width
Sync2 -120° to +120° Phase difference between right LFO Mod and Pan
Dpth2* 0-100% Right Mod and Pan depth
Res -100 to +100 Resonance
Width* 0-100% Panning width
Orbits processes the left and
right inputs independently with a
pair of modulated delay/auto
panners. This effect can be used
to create spatial effects via a com-
bination of Doppler and level pan-
ning.
In the Orbits effect, Pulse Width
controls allow independent adjust-
ment of left and right LFOs from
full left to full right skew. (At 0, the
sinewave becomes a sawtooth
with a fast rise and slow fall.) Depth
controls provide adjustment of Mod
and Pan depth from 0-100%. Width
allows adjustment of the panning
depth from 0 (mono) to 100 (maxi-
mum stereo spread).
Orbits
* = Interpolated; ( ) = Option of preceding parameter
