Lexmark 7014-636 - Output bin LED and Lens Removal

4-98
7014-xxx
Output bin LED and lens removal
1. Disconnect the output LED cable from the controller board.
2. Remove the controller board cage. See “Controller board cage” on page 4-14.
3. Press the tab (A) securing the lens to the tub assembly.
4. Pull down on the lens and LED and remove it from the tub.
A
