Lexmark 7014-636 - Option Board Installs and Removals; Lifting the Scanner to the up Position

4-102
7014-xxx
Option board installs and removals
Note: This information is also available in the X 46x series user guide.
Lifting the Scanner to the up position
1. Turn the two rear frame assembly locks counter-clockwise to the unlock position.
2. Lift the scanner assembly to the up position. The kickstand will lock into place.
