Lexmark 7014-636 - Media Feed Clutch with Cable Removal

4-50
7014-xxx
Media feed clutch with cable removal
1. Remove the main motor gear drive. See “Main motor gear drive removal” on page 4-40.
2. Remove the duplex. See “Duplex removal” on page 4-19.
3. Disconnect the media feed clutch cable (A) from J34 on the engine board.
4. Un route the cable from the bottom of the printer.
A
