• Keep the printer:
– Away from the direct airflow of air conditioners, heaters, or ventilators
– Free from direct sunlight, humidity extremes, or temperature fluctuations
– Clean, dry, and free of dust
• Allow the following recommended amount of space around the printer for proper ventilation:
1
2
3
4
5
1 385 mm (15.16 in.)
2 609.6 mm (24.0 in.)
3 100 mm (3.94 in.)
4 100 mm (3.94 in.)
5 100 mm (3.94 in.)
Printer configurations
Notes:
• The printer stand is a cabinet that can be converted into a caster base.
• If used with a printer stand, then the printer supports only one optional 550-sheet tray.
• If used with a caster base, then the printer supports a maximum of three optional 550-sheet trays.
Learning about the printer 15
