• Do not unplug the fan cable upon opening the metal panel.
2 Unplug the printer hard disk interface cable from the system board, leaving the cable attached to the printer hard
disk. To unplug the cable, squeeze the paddle at the plug of the interface cable to disengage the latch before pulling
the cable out.
3 Remove the printer hard disk.
4 Reattach the system board cover.
Additional printer setup 41
