132 errors
132 error messages
Error code Description Action
132.01 TDS baseline too low. Go to
“Toner density sensor service check” on
page 141.
132.02 TDS baseline too high.
132.03 TDS baseline excessive range.
132.16 TDS calibration at maximum.
132.17 TDS calibration too low.
132.18 TDS calibration too close to baseline.
132.32 PC drum measurement too high.
132.33 PC drum measurement too dierent from
calibration.
132.34 PC drum measurement too close to baseline.
Toner density sensor service check
Action Yes No
Step 1
Remove the transfer roll, and check for loose toner blocking the
toner density sensor.
Is it free of loose toner?
Go to step 2. Clean the sensor.
Step 2
Check the toner density sensor for proper operation:
a Lower the ACM assembly.
b Move the toner density sensor wiper from left to right.
Does it move freely?
Go to step 3. Reinstall the wiper
properly. If it still
cannot move freely,
replace the toner
density sensor. See
“Toner density
sensor removal” on
page 295.
Step 3
Check the toner density sensor cable for proper connection to the
controller board.
Is it properly connected?
Go to step 4. Reseat the cable.
Step 4
Check the toner density sensor cable for damage and pinch points.
Is it free of damage?
Replace the
controller board. See
“Controller board
removals” on
page 247.
Replace the toner
density sensor. See
“Toner density
sensor removal” on
page 295.
4514-6xx
Diagnostics and troubleshooting
141
