To run the Feed test:
1 From the Diagnostics menu, navigate to:
Input Tray Tests > Feed Tests
2 Choose the input source. All installed sources appear.
3 Choose any of the following:
• Single—Feeds a single page.
• Continuous—Continuously feeds pages until X is pressed.
Sensor Test
Use this test to determine if the input tray sensors are working correctly.
1 From the Diagnostics menu, navigate to:
Input Tray Tests > Sensor Test
2 Select the input source. All installed sources appear.
Not all sensors appear for all trays. The following table indicates which tray sensors are available for each
input source:
Input source Tray empty sensor Pass through sensor
Standard tray
Optional 250‑/550-sheet tray
Multipurpose feeder
3 Manually actuate each sensor. The tray empty sensor can be actuated by hand; however, a sheet of paper
can be used to cover the pass through sensor.
4 Press X to exit the test.
Output Bin Tests
Feed Tests
This test
verifies
that media can be fed to a
specific
output bin. No information is printed on the media.
To run this test:
1 From the Diagnostics menu, navigate to:
Output Bin Tests > Feed Tests
2 Select the output bin into which you want the paper to exit. All installed output bins appear.
3 Select one of the following:
• Single—Feeds a single page.
• Continuous—Continuously feeds pages until X is pressed.
4514-6xx
Service menus
182
