Actions Yes No
Step 12
Replace the cartridge gearbox. See
“Cartridge gearbox removal”
on page 238.
Does the problem remain?
Go to step 13. The problem is
solved.
Step 13
Check connection JCART1 on the controller board and the
connection on the cartridge gearbox.
Are the connections properly connected?
Go to step 15. Go to step 14.
Step 14
Replace the connections.
Does the problem remain?
Go to step 15. The problem is
solved.
Step 15
Replace the cartridge gearbox. See “Cartridge gearbox removal”
on page 238.
Does the problem remain?
Go to step 16. The problem is
solved.
Step 16
Replace the controller board. See
“Controller board removals” on
page 247.
Does the problem remain?
Contact the next
level of support.
The problem is
solved.
Paper curl check
4514-6xx
Diagnostics and troubleshooting
56
