Lexmark MS610dn

e Secure the cable at the pick/lift motor gearbox using cable ties. Cut o any excess cable tie.
MPF gearbox removal
1 Remove the left cover. See “Left cover removal” on page 228.
2 Remove the main drive gearbox. See “Main drive gearbox removal” on page 229.
3 Remove the front door. See “Front door removal” on page 281.
4514-6xx
Parts removal
234
