Lexmark MS826 Service Manual

Mailbox controller board removal
1 Remove the mailbox top cover. See “Mailbox top cover removal” on page 648.
2 Remove the mailbox left cover. See “Mailbox left cover removal” on page 654.
3 Disconnect all cables (J1B, J5, J4D, J2A, J4C, J2B, J4B, J2C, J4A, J8, J1A, J3B, J7, J6, J12, and J3T), and
then remove the two screws (A) from the controller board.
4064
Parts removal
667

Lexmark MS826 Specifications

General

Print Technology	Monochrome Laser
Print Speed	Up to 70 ppm
Print Resolution	1200 x 1200 dpi
Duplex Printing	Standard
Monthly Duty Cycle	Up to 350, 000 pages
Processor Speed	1 GHz
Recommended Monthly Page Volume	5, 000 - 75, 000 pages
First Page Out	As fast as 4 seconds
Standard Memory	1024 MB
Maximum Input Capacity	4, 400 pages
Connectivity	USB, Ethernet, Wireless
Media Types Supported	Cardstock, Envelopes, Plain paper
Operating Systems Supported	Windows, macOS, Linux
Standard Paper Input	650 pages
Weight	52.5 lbs
