Head
22
⏐
GA10218_0101 - 5/2002
2.2.2.2 Digital Out (Control)
The following relay outputs Fig. 3/8 are available for further signal proces-
sing. The maximum rating for the relay contacts is 60V AC/1A.
The contacts are numbered from bottom to top.
The pin assignment for contacts 8 to 16 follows the same order as for pins
5 to 7.
For further information see chapter 6.6.4.4
2.2.2.3 Digital In (Control 2)
These inputs can be used to control the PhoeniXL with a programmable
logic control (PLC).
These inputs Fig. 3/6 are working only, if the correct location of control is
chosen. See chapter 6.6.4.1
To avoid a mistake between the connection Control 2 and Record, pin 1
and 4 are blocked. When using the connectors the guiding nose for pin 1
and 4 must be removed.
For further information see chapter 6.6.4.5
Pin Assignment
1 PLC in free selectable
2 PLC in free selectable
3 PLC in free selectable
4GND
5 to 7 Digital out free selectable, 5 center contact, 6 normally open
contact, 7 normally closed contact
8 to 10 Digital out free selectable
11 to 13 Digital out free selectable
14 to 16 Digital out free selectable
Pin Assignment
1 PLC in free selectable
2 PLC in free selectable
3 PLC in free selectable
4PLC GND
