6.6.4.6 Scaling Recorder Output
Main menu > Settings > Interfaces > Scaling Recorder Output
Here the scaling of the recorder output can be adjusted. This adjustment
is possible with only when the signal LR lin or LR log is chosen.
Example:
Upper limit value is adjusted to 10
-5
(= 10V)
Scaled to 5 V /decade
Lower limit value consequently is 10
-3
(= 0 V)
6.6.4.7 PLC Sample Rate
Main menu > Settings > Interfaces >PLC Sample rate
6.6.5 Miscellaneous
Main menu > Settings > Miscellaneous
The actual date and time, the prefered language and the mains frequency
can be set in this submenu.
Softkey 2: Decrease the decade
The decade of the upper leakrate can be decreased
Softkey 3: Decrease scaling
Decrease scaling of the previously adjusted value in steps of 0.5, 1, 2,
2.5, 5, 10 Volt/decade. The complete array is covers 10 V.
Softkey 5: ?
Help text.
DSoftkey 6: Increase decade
The decade of the upper leakrate can be increased
Softkey 7: Increase scaling
Increase scaling of the previously adjusted value in steps of 0.5, 1, 2, 2.5,
5, 10 Volt/decade. The complete array covers 10 V.
Softkey 2: Decrease the PLC sample rate of the PLC control
Decreasing the PLC sample rate down to the minimum of 10 ms. This
might be necessary if exchanging an L200 to the PhoeniXL to stay com-
patible.
Softkey 3: Increase the PLC sample rate of the PLC control
Increasing the PLC sample rate to the maximum of 100 ms.
