Description
22
300554859_002_C0 - 11/2016 - © Leybold
Part No.
Connection cable C14 – valve plug, (Control 110/230 VAC SECUVAC valve), 1.8 m
5 m
Connection cable M8 - valve plug
(Control 24 VDC SECUVAC valve), (rectangular cable connector on the valve side) 1.8 m
5 m
Connection cable M8 - valve plug
(Control 24 VDC SECUVAC valve), (square-shaped cable connector on the valve side) 1.8 m
5 m
Connection cable M8 –SUB-D plug (Control 24 VDC SECUVAC valve), 1.8 m
5 m
Connection cable TURBOVAC i M8 - bare wire ends (Connection 24 VDC accessories)
800103V0033
800103V0035
800103V0034
800103V0036
800103V0040
800103V0041
800103V0038
800103V0039
800110V0017
LEYASSIST software for TMPs 230439V01
Air cooling TURBOVAC 350-450 i radial
Air cooling TURBOVAC 90 i radial
800136V0005
800136V0007
Water cooling TURBOVAC i(X) 800135V0005
Water cooling for TURBOVAC SL 80 with G 1/8”connections
incl. 2 hose nipples G 1/8”, Outer Ø 8 mm for water hose,
2 sealing rings approx. 10x4x1, screws
800135V0001
Air cooler for TURBOVAC SL 80
4 screws M4x10, DIN 912
800136V0001
For TURBOVAC i:
Venting valve, 24 V DC, G 1/8“
Power failure venting valve 24 V DC, G 1/8“
Purge gas valve, 24 V DC, G 1/8“, 24 sccm
800120V0012
800120V0022
800120V0013
Purge gas throttle, G 1/8“, 24 sccm
800120V0014
Air filter for TMP, G 1/8“ 800110V0022
For TURBOVAC SL 80:
Purge gas and venting valve 0,4 mbar·l/s at 1 bar, 24 V DC
DN 10 KF – G1/4”
Pump connection: Adapter M8 – DN-16-KF
incl. O-ring 9.25 x 1.78 and
Adapter centering ring DN 10/16 KF with sinter filter
Gas side connection: G1/4-in. adapter with filter
Including O-ring and gasket
Connection cable:
Accessory cable M8 – bare wire ends
Note:
For space reasons, when the frequency converter is installed at the side,
only either the air-cooler or a purge gas valve can be connected.
800152V0013
800110V0011
800110V0012
800110V0017
800152V0013
800110V0012
800110V0011
