LEYBOLD TURBOLAB 80 User Manual

Installation
36
300554859_002_C0 - 11/2016 - © Leybold
Fig. 3.9 Connections at the TURBOVAC SL 80
High-vacuum flange
Connection thread for the
vibration sensor
Closure screw for the
purge gas connection
Forevacuum connection
(is connected)
Cooling water connection
Water cooling (option)
Fig. 3.10 Connections at the TURBOVAC 90 i, TURBOVAC 250 i is similar
High-vacuum flange
Purge gas connection
G1/8“
Mounting surface for
water cooling
Venting connection
G1/8“
Forevacuum connection
USB interface X106
RS 485 interface X104
DC input DC IN X10
REMOTE interface X1
LEDs
Accessory connection
DC OUT (M8) X201
