Designs and specifications are subject to change without notice.
Weight and dimensions shown are approximate.
Specifications
29
GENERAL
Head System Four head helical scan
azimuth system
Power Source AC 100-240V, 50/60Hz
Power Consumption Approx. 22 Watts
Dimensions (WxHxD) 360 x 98 x 274 mm
(14.2" x 3.9" x 10.8")
Operating Temperature 5 °C~35 °C (41 °F~95 °F)
Operating Humidity Less than 80% RH
Timer 12-hour display type with AM, PM
Weight Approx. 3.4 kg (7.5 lbs)
Tape Speed 33.35 mm/sec (SP mode)
16.67 mm/sec (LP mode)
11.12 mm/sec (EP mode)
Tape Width 12.7 mm
Maximum Recording 2 HOURS (T-120, SP mode)
Time 6 HOURS (T-120, EP mode)
8 HOURS (T-160, EP mode)
Rewind Time About 60 seconds (T-120)
TUNER
Antenna 75 ohms (UHF), 75 ohms (VHF)
VHF Output Signal Channel 3 or 4 (Switchable)
Channel Coverage VHF; 2-13
UHF; 14-69
CATV; 4A, A~W, W+1~W+84, A-5~A-1
VIDEO
Video Signal System EIA Standard (525 lines, 60 fields)
NTSC type color signal
Input 1.0 Vp-p 75 ohms unbalanced
Output 1.0 Vp-p 75 ohms unbalanced
Signal to Noise Ratio More than 43 dB (SP mode)
AUDIO
FM audio
Frequency Range 20Hz to 20kHz
Dynamic Range More than 83 dB
Channel Separation More than 55 dB
Conventional audio
Input -6.0 dBm more than 47 kohms (LINE)
Output -6.0 dBm less than 1.5 kohms (LINE)
S/N Ratio More than 43 dB (SP mode)
Frequency Range 200 Hz to 10kHz (SP mode)
Supplied Accessories
Coaxial Cable (1)
Audio Cable (1)
Video Cable (1)
Remote control (1)
