31
EXTERNAL EQUIPMENT SETUP
PC SETUP
When using the remote control, aim it at the remote control sensor on the SET.
When connecting with a D-sub 15 pin cable
Connect the signal cable from the monitor output socket
of the PERSONAL COMPUTER to the PC input socket
of the set.
Connect the audio cable from the PC to the AUDIO IN
(RGB) sockets of the set.
Press the INPUT button to select RGB PC.
Switch on the PC, and the PC screen appears on the set.
The set can be operated as a PC monitor.
1
2
3
4
HDMI IN
VIDEO AUDIO(MONO)
L
R
AV IN
VIDEO
AUDIO
Y
PB
PR
L
R
COMPONENT IN
RGB IN (PC)
AUDIO IN
(RGB)
RGB OUTPUT
AUDIO
►Connect the signal input cable and tighten the screws by turn-
ing them clockwise.
NOTE
► User must use shielded signal interface cables (D-sub 15 pin cable) with ferrite cores to maintain standard
compliance for the product.
