APPENDIX
■ The specifications shown above may be changed without prior notice for quality improvement.
LCD Panel
Screen Type
508.05 mm Wide (20 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 508.05 mm
Pixel Pitch 0.2766 mm (H) x 0.2766 mm (V)
Video Signal
Max. Resolution 1600 x 900 @ 60 Hz
Recommended Resolution 1600 x 900 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync
Input Connector
CVBS, TV, D-Sub Analog, HDMI, PC Audio In, component
Power
Rated Voltage AC 100-240 V~ 50 / 60 Hz 0.9 A
Power Consumption
On Mode : 42W (typ.)
Sleep Mode 1 W (RGB)
Off Mode 0.5 W
Tilt Tilt Range
-5° to 15°
Dimensions (Width x Height x Depth)
Weight
482.3 mm x 384.2 mm x 221.6 mm
(18.98 inch x 15.12 inch x 8.72 inch)
4.6 kg (10.14 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
M2062A
PRODUCT SPECIFICATIONS
