■ The specifications shown above may be changed without prior notice for quality improvement.
LCD Panel
Screen Type
686 mm Wide (27 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 686 mm
Pixel Pitch 0.3114 mm (H) x 0.3114 mm (V)
Video Signal
Max. Resolution 1920 x 1080 @ 60 Hz
Recommended Resolution
1920 x 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync
Input Connector CVBS, TV, D-Sub Analog, HDMI, PC Audio In, component
Power
Rated Voltage
AC 100-240 V~ 50 / 60 Hz 1.2 A
Power Consumption
On Mode : 60 W (typ.)
Sleep Mode 1 W (RGB)
Off Mode 0.5 W
Tilt Tilt Range -5° to 15°
Swivel Swivel Range 358°
Dimensions (Width x Height x Depth)
Weight
649.1 mm x 485 mm x 210 mm
(25.56 inch x 19.09 inch x 8.27 inch)
7.2 kg (15.87 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
M2762A
PRODUCT SPECIFICATIONS
