82
APPENDIX
APPENDIX
■ The specifications shown above may be changed without prior notice for quality improvement.
M2262A
PRODUCT SPECIFICATIONS
LCD Panel
Screen Type
546.86 mm Wide (21.53 inch) TFT (Thin Film Transistor)
LCD (Liquid Crystal Display) Panel
Visible diagonal size: 546.86 mm
Pixel Pitch 0.248 mm (H) x 0.248 mm (V)
Video Signal
Max. Resolution 1920 x 1080 @ 60 Hz
Recommended Resolution
1920 x 1080 @ 60 Hz
Horizontal Frequency 30 kHz to 69 kHz
Vertical Frequency 56 Hz to 61 Hz
Synchronization Type Separate Sync
Input Connector CVBS, TV, D-Sub Analog, HDMI, PC Audio In, component
Power
Rated Voltage
AC 100-240 V~ 50 / 60 Hz 1.2 A
Power Consumption
On Mode : 45 W (typ.)
Sleep Mode 1 W (RGB)
Off Mode 0.5 W
Tilt Tilt Range -5° to 15°
Dimensions (Width x Height x Depth)
Weight
517.2 mm x 399.8 mm x 221.6 mm
(20.36 inch x 15.74 inch x 8.72 inch)
4.7 kg (10.36 lb)
Environmental
conditions
Operating Temperature
Operating Humidity
10 °C to 35 °C
20 % to 80 %
-10 °C to 60 °C
5 % to 90 %
Storage Temperature
Storage Humidity
