Oper
a
tion and Saf
ety Manual
98
Hydraulic Oil Speci
fications
Use temperature
Oil type
Minimum air temperature
＞
15.8
℉
(-9
℃
)
L-HM 46 antiwear hydraulic oil
(-
33
℃
)-27.4
℉＜
minimum air temperature
≤15.8
℉
(-9
℃
)
L-HV 46 low temperature hudraulic oil
(-
39
℃
)-38.2
℉＜
minimum air temperature ≤
-27.4
℉
(-
33
℃
)
L-HS 46ultralow temperature hudraulic oil
Minimum air temperature ≤
-38.2
℉
(-
39
℃
)
10# aviation hydraulic oil
105
107
Table of Contents
Default Chapter
3
Foreword
3
Safety Precautions
4
Table of Contents
5
Chapter 1 Safety
9
Description
11
Maintenance of Safety Signs and Decals
11
Workstation Safety
11
Battery Safety
17
Lock after each Use
18
Chapter 2 Machine Nomenclature
20
Ground Controls
22
Key Switch
22
Emergency Stop Switch
22
Platform Lift Switch
22
Chapter 3 Controls
22
Platform Controls
23
Horn Button
23
Lift Switch
23
Display
23
Emergency Stop Switch
23
Drive/Lift Control Lever
24
Drive Function Button
24
Enabling Switch
24
Indoor or Outdoor Mode Selection
24
Drive Speed Button
24
Steer Switch
24
Basic Principles
26
Chapter 4 Pre-Operation Inspection
26
Workstation Inspection
28
General Information
28
Chapter 5 Workstation Inspection
28
Function Test
30
Tests from the Ground Controls
30
Chapter 6 Function Test
30
General Information
30
Test the Emergency Stop Switch
31
Test of Lifting/Lowering Function
31
Platform Controller Test
31
Horn Test
31
Lift Function and Function Enable Switch Test
32
Steering Test
32
Driving and Braking Function Test
33
Driving Function Test
33
Pothole Deployment Height When Driving
33
Operation of Tilt Sensor Test
34
Pothole Guard Test
34
Pothole Deployment Height When Lifting
34
Pothole Guard Not Deployed Alarm Height
35
Emergency Stop
36
Emergency Lowering
36
Operation from the Ground Controls
36
Chapter 7 Operating Instructions
36
General Information
36
Platform Positioning
38
Operation from the Platform Controls
38
Steering
38
Drive
38
Drive Speed Option
39
Driving the Machine from the Ground
39
Battery Level as Shown on LED Display
39
Using the Safety Prop
40
How to Stow the Guardrail
40
How to Erect the Guardrail
42
Extending and Retracting the Extending Platform Deck
42
Error Codes
43
Troubleshooting Guide
45
Historical Error Status
47
Releasing the Brake
49
Chapter 8 Transport and Lifting Instructions
49
Transport Safety
51
Center of Gravity
52
Loading the Machine with a Forklift
53
Lifting Precautions
54
Parking and Storage
54
Chapter 9 Decals and Warning Labels
55
Decal List
56
Decal Diagram
59
Platform Load Capacity
91
Chapter 10 Specifications
91
Operating Specifications
93
Hydraulic Oil Specifications
101
Chapter 11 Maintenance Schedule
103
4
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the LGMG AS3246 and is the answer not in the manual?
Ask a question
LGMG AS3246 Specifications
General
Brand
LGMG
Model
AS3246
Category
Lifting Systems
Language
English
