LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
93
Table 33 – AS4650 Operating Specifications
(In door/ Out door)
Item
Parameter
Maximum working
height
In door
51.8ft (15.8m)
Out door
32.8ft (10m)
Maximum height of
platform
In door
45.3ft (13.8m)
Out door
26.2ft (8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward/ backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Traveling speed of machine
(Stowed position)
1.9mph (3Km/h)
Traveling speed of machine (lifting
position)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
80/65
Minimum turning radius (exterior)
9.35ft (2.85m)
Gradeability
25%
Overall length
With ladder
9.2ft (2.80m)
Without ladder
8.7ft (2.65m)
Overall width
4.3ft(1.3m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
8.66ft×3.7ft
(2.64m×1.12m)
Wheelbase (front/rear)
87.4in(2220mm)
Ground clearance
(stowed/lifting position)
4.1in/0.79in
(105mm/20mm)
Overall height
Rails Folding
6.4ft (1.94m)
Rails un-folding
9ft (2.74m)
Overall weight
7870lbs (3570Kg)
Battery
Output Voltage(V)
12
Capacity (AH)
25A/280;75A/70
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3626psi (25MPa)
Tire contact pressure
226.7psi (1563.13KPa)
Ground pressure
231.4psf (11.08KPa)
10.1 Hydraulic Oil
Specifications
△
! Notice
When filling the hydraulic oil tank, it is a
requirement to use the proper hydraulic
oil in accordance with the work site
environment and ambient temperature
with reference to the following:
⚫ L-HM 46 antiwear hydraulic oil: minimum air
temperature＞15.8℉(-9℃);
⚫ L-HV 46 low temperature hydraulic oil: (-
33℃)-27.4℉＜minimum air
temperature≤15.8℉(-9℃);
⚫ L-HS 46 Ultralow temperature hydraulic oil: (-
39℃)-38.2℉＜minimum air temperature≤-
27.4℉(-33℃)
⚫ 10# aviation hydraulic oil: minimum air
temperature ≤-38.2℉(-39℃);
⚫ Oil level in the oil tank when
SS1230E/SS1432E/SS1932E is stowed after
the whole machine has been fully elevated,
steered from stop-to-stop, and driven is 1
gal. (4L).
⚫ Oil level in the oil tank when AS1930/
AS1930EAS1932/AS1932E is stowed after
the whole machine has been fully elevated,
steered from stop-to-stop, and driven is 1.6
gal. (6L).
