LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
85
Table 17-SS1230E Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum working height
18.4ft (5.6m)
Maximum height of platform
12ft (3.6m)
Extending size of platform
2ft (0.6m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2mph (3.2Km/h)
Max Traveling speed (Elevated)
0.3mph (0.5Km/h)
Lifting/lowering speed (S)
25/18
Minimum turning radius
4.9ft (1.5m)
Gradeability
25%
Overall length
With ladder
5ft (1.53m)
Without ladder
4.4ft (1.35m)
Tire size (diameter×width)
9.1in×3.1in
(230mm×80mm)
Overall width
2.5ft (0.76m)
Dimension of working platform
(L×W)
4.4ft×2.3ft
(1.35m×0.7m)
Wheelbase (front/rear)
44.1in(1120mm)
Ground clearance (stowed/lifting
position)
1.97in/0.63in
(50mm/16mm)
Overall height
Rails Folding
6ft (1.82m)
Rails un-folding
6.8ft (2.06m)
Overall weight
1940lbs (880Kg)
Battery
Output Voltage(V)
12
Capacity (AH)
25A/175;75A/45
Charger
Nom. AC Input Voltage
100-240VAC
Max.DC Output Current
15
Nominal .DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
1884psi (13MPa)
Tire contact pressure
162psi (1116.71KPa)
Ground pressure
223.7psf (10.71KPa)
Table 16 - SS1432E Operating Specifications
(In door)
Item
Parameter
Maximum working height
20.7ft (6.3m)
Maximum height of platform
14.1ft (4.3m)
Extending size of platform
2ft (0.6m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Traveling speed of machine
(Stowed position)
2mph (3.2Km/h)
Traveling speed of machine (lifting
position)
0.3mph (0.5Km/h)
Lifting/lowering speed (S)
25/20
Minimum turning radius
4.9ft (1.5m)
Gradeability
25%
Overall length
With ladder
5ft (1.53m)
Without ladder
4.4ft (1.35m)
Overall width
2.65ft (0.81m)
Tire size (diameter×width)
9.1in×3.1in
(230mm×80mm)
Dimension of working platform
(L×W)
4.4ft×2.3ft
(1.35m×0.7m)
Wheelbase (front/rear)
44.1in(1120mm)
Ground clearance (stowed/lifting
position)
1.97in/0.63in
(50mm/16mm)
Overall height
Rails Folding
6.2ft (1.9m)
Rails un-folding
7.1ft (2.15m)
Overall weight
2172lbs (985Kg)
Battery
Output Voltage(V)
12
Capacity (AH)
25A/280;75A/70
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
15
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
2174psi (15MPa)
Tire contact pressure
213.4psi (1471.5KPa)
Ground pressure
228.5psf (10.94KPa)
