Table 19 - SS1932E Operating Specifications
(In door)
Item
Parameter
Maximum working height
24.6ft (7.5m)
Maximum height of platform
18ft (5.5m)
Extending size of platform
2ft (0.6m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2 mph (3.2Km/h)
Max Traveling speed (Elevated)
0.3mph (0.5Km/h)
Lifting/lowering speed (S)
32/27
Minimum turning radius
4.9ft (1.5m)
Gradeability
25%
Overall length
With ladder
5.02ft (1.53m)
Without ladder
4.4ft (1.35m)
Overall width
2.65ft (0.81m)
Tire size (diameter×width)
9.1in×3.1in
(230mm×80mm)
Dimension of working platform
(L×W)
4.4ft×2.3ft
(1.35m×0.7m)
Wheelbase (front/rear)
44.1in(1120mm)
Ground clearance (stowed/lifting
position)
1.97in/0.63in
(50mm/16mm)
Overall height
Rails Folding
6.56ft (2.0m)
Rails un-folding
7.46ft (2.27m)
Overall weight
2866lbs (1300Kg)
Battery
Output Voltage(V)
12
Capacity (AH)
25A/280;75A/70
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
15
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
2176psi (15MPa)
Tire contact pressure
211psi(1454.66KPa)
Ground pressure
281.1psf(13.46Kpa)
Table 20-AS1930E Operating Specifications
(Indoor )
Item
Parameter
Maximum working height
25.6ft (7.8m)
Maximum height of platform
19ft (5.8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2.2mph (3.5Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
16/28
Minimum turning radius (exterior)
5.6ft (1.72m)
Gradeability
25%
Overall length
With ladder
6.1ft (1.86m)
Without ladder
5.51ft (1.68m)
Overall width
2.5ft (0.76m)
Tire size (diameter×width)
12.7in×4in
323mm×100mm
Dimension of working platform
(L×W)
5.3ft×2.4ft
(1.63m×0.74m)
Wheelbase (front/rear)
53in (1350mm)
Ground clearance (stowed/lifting
position)
3.15in/0.79in
(80mm/20mm)
Overall height
Rails Folding
6ft (1.84m)
Rails un-folding
7ft (2.14m)
Overall weight
3549lbs (1610Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3046psi (21MPa)
Tire contact pressure
156psi (1074.83 KPa)
Ground pressure
283.8psf (13.5 9KPa)
