LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
87
Table 21-AS1932E Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum working height
25.6ft (7.8m)
Maximum height of platform
19ft (5.8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2.2mph (3.5Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
16/28
Minimum turning radius (exterior)
5.74ft (1.75m)
Gradeability
25%
Overall length
With ladder
6.1ft (1.86m)
Without ladder
5.51ft (1.68m)
Overall width
2.7ft (0.81m)
Tire size (diameter×width)
12.7in×4in
323mm×100mm
Dimension of working platform
(L×W)
5.3ft×2.4ft
(1.63m×0.74m)
Wheelbase (front/rear)
53in (1350mm)
Ground clearance (stowed/lifting
position)
3.15in/0.79in
(80mm/20mm)
Overall height
Rails Folding
6ft (1.84m)
Rails un-folding
7ft (2.14m)
Overall weight
3571lbs (1620Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3046psi (21MPa)
Tire contact pressure
156psi (1074.83 KPa)
Ground pressure
283.8psf (13.5 9KPa)
Table 22 - AS2632E Operating Specifications
(In door)
Item
Parameter
Maximum working height
32.8ft (10m)
Maximum height of platform
26.2ft (8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2.2mph (3.5Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
31/40
Minimum turning radius
7ft (2.15m)
Gradeability
25%
Overall length
With ladder
7.9ft (2.4m)
Without ladder
7.4ft (2.25m)
Overall width
2.7ft(0.83m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
7.4ft×2.7ft
(2.26m×0.81m)
Wheelbase (front/rear)
73in(1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.98in
(100mm/25mm)
Overall height
Rails Folding
6.4ft (1.95m)
Rails un-folding
7.6ft (2.32m)
Overall weight
4718lbs (2140Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3046psi (21MPa)
Tire contact pressure
126.3psi (871.10KPa)
Ground pressure
264.4psf (12.66KPa)
