LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
88
Table 23 - AS2646E Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum working height
32.8ft (10m)
Maximum height of platform
26.2ft (8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max. Traveling speed (Stowed)
2.2mph (3.5Km/h)
Max. Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
35/40
Minimum turning radius
7.5ft (2.3m)
Gradeability
25%
Overall length
With ladder
8ft (2.42m)
Without ladder
7.4ft (2.25m)
Overall width
3.9ft (1.18m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
7.4ft×3.8ft
(2.26m×1.15m)
Wheelbase (front/rear)
73in(1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.79in
(100mm/20mm)
Overall height
Rails Folding
5.7ft (1.73m)
Rails un-folding
7.5ft (2.30m)
Overall weight
5357lbs (2430Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/488;75A/132
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3046psi (21MPa)
Tire contact pressure
177.76psi (1225.62KPa)
Ground pressure
222.85psf (10.67KPa)
Table 24-AS3246E Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum working height
39.4ft (12m)
Maximum height of platform
32.8ft (10m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Traveling speed of machine (Stowed
position)
2.2mph
(3.5Km/h)
Traveling speed of machine (lifting
position)
0.5mph
(0.8Km/h)
Lifting/lowering speed (S)）
58/48
Minimum turning radius
7.5ft (2.3m)
Gradeability
25%
Overall length
With ladder
8ft (2.42m)
Without ladder
7.4ft (2.25m)
Overall width
3.9ft (1.18m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
7.4ft×3.8ft
(2.26m×1.15m)
Wheelbase (front/rear)
73in (1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.79in
(100mm/20mm)
Overall height
Rails Folding
5.7ft (1.73m)
Rails un-folding
7.5ft (2.30m)
Overall weight
6614lbs
(3000Kg)
Battery
Output Voltage(V)
6
Capacity (min)
25A/488;75A/13
2
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
< 70dBA
Platform environment noise radiation
< 70dBA
System pressure
3046psi
21(MPa)
Tire Contact Pressure
163.3psi
1225.25 kPa
Ground pressure
247.5psf
11.85KPa
