LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
89
Table 25 - AS4046E Operating Specifications
(In door)
Item
Parameter
Maximum working height
46ft (14m)
Maximum height of platform
39.4ft (12m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Traveling speed of machine
(Stowed position)
2.2mph (3.5Km/h)
Traveling speed of machine (lifting
position)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
58/60
Minimum turning radius (exterior)
7.5ft (2.3m)
Gradeability
25%
Overall length
With ladder
8.1ft (2.47m)
Without ladder
7.4ft (2.25m)
Overall width
3.9ft(1.18m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
7.4ft×3.8ft
(2.26m×1.15m)
Wheelbase (front/rear)
73in(1850mm)
Ground clearance
(stowed/lifting position)
3.94in/0.79in
(100mm/20mm)
Overall height
Rails Folding
6.5ft (1.99m)
Rails un-folding
8.4ft (2.56m)
Overall weight
6967lbs (3160Kg)
Battery
Output Voltage(V)
12
Capacity (AH)
25A/280;75A/70
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3046psi (21MPa)
Tire contact pressure
190.98psi (1316.78KPa)
Ground pressure
280.07psf (13.41KPa)
Table 26 – AS4650E Operating Specifications
(In door/Out door)
Item
Parameter
Maximum working
height
In door
51.8ft (15.8m)
Out door
32.8ft (10m)
Maximum height of
platform
In door
45.3ft (13.8m)
Out door
26.2ft (8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward/ backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Traveling speed of machine
(Stowed position)
2.2mph (3.5Km/h)
Traveling speed of machine (lifting
position)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
80/65
Minimum turning radius (exterior)
9.35ft (2.85m)
Gradeability
25%
Overall length
With ladder
9.2ft (2.80m)
Without ladder
8.7ft (2.65m)
Overall width
4.3ft(1.3m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
8.66ft×3.7ft
(2.64m×1.12m)
Wheelbase (front/rear)
87.4in(2220mm)
Ground clearance
(stowed/lifting position)
4.1in/0.79in
(105mm/20mm)
Overall height
Rails Folding
6.4ft (1.94m)
Rails un-folding
9ft (2.74m)
Overall weight
7870lbs (3570Kg)
Battery
Output Voltage(V)
12
Capacity (AH)
25A/280;75A/70
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3046psi (21MPa)
Tire contact pressure
226.7psi (1563.13KPa)
Ground pressure
231.4psf (11.08KPa)
