LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
90
Table 27 – AS1930 Operating Specifications
(Indoor)
Item
Parameter
Maximum working height
25.6ft (7.8m)
Maximum height of platform
19ft (5.8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2 mph (3.2Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
16/28
Minimum turning radius
5.4ft (1.65m)
Gradeability
25%
Overall length
With ladder
6ft (1.83m)
Without ladder
5.4ft (1.65m)
Overall width
2.7ft (0.81m)
Dimension of working platform
(L×W)
5.3ft×2.4ft
(1.63m×0.74m)
Wheelbase (front/rear)
52in (1320mm)
Ground clearance (stowed/lifting
position)
2.36in/0.79in
(60mm/20mm)
Overall height
Rails Folding
6ft (1.82m)
Rails un-folding
7ft (2.12m)
Overall weight
3483lbs (1580Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3481psi (24MPa)
Tire contact pressure
156psi (1074.83 KPa)
Ground pressure
283.8psf (13.5 9KPa)
Table 28 – AS1932 Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum working height
25.6ft (7.8m)
Maximum height of platform
19ft (5.8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
2 mph (3.2Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
16/28
Minimum turning radius
5.6ft (1.7m)
Gradeability
25%
Overall length
With ladder
6.ft (1.83m)
Without ladder
5.41ft (1.65m)
Overall width
2.7ft (0.81m)
Dimension of working platform
(L×W)
5.3ft×2.4ft
(1.63m×0.74m)
Wheelbase (front/rear)
52in (1320mm)
Ground clearance (stowed/lifting
position)
2.36in/0.79in
(60mm/20mm)
Overall height
Rails Folding
6ft (1.82m)
Rails un-folding
7ft (2.12m)
Overall weight
3527lbs (1600Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3481psi (24MPa)
Tire contact pressure
156psi (1074.83 KPa)
Ground pressure
283.8psf (13.5 9KPa)
