Table 29 – AS2632 Operating Specifications
(In door)
Item
Parameter
Maximum working height
32.8ft (10m)
Maximum height of platform
26.2ft (8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
1.9mph (3Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
31/40
Minimum turning radius
7ft (2.15m)
Gradeability
25%
Overall length
With ladder
7.9ft (2.4m)
Without ladder
7.4ft (2.25m)
Overall width
2.7ft(0.83m)
Tire size (diameter×width)
15in×5.1in
380mm×130mm
Dimension of working platform
(L×W)
7.4ft×2.7ft
(2.26m×0.81m)
Wheel tread
27.6in(700mm)
Wheelbase (front/rear)
73in(1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.98in
(100mm/25mm)
Overall height
Rails Folding
6.4ft (1.95m)
Rails un-folding
7.6ft (2.32m)
Overall weight
4718lbs (2140Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/447;75A/115
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3481psi (24MPa)
Tire contact pressure
126.3psi (871.10KPa)
Ground pressure
264.4psf (12.66KPa)
Table 30 - AS2646 Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum occupant capacity
2
Maximum working height
32.8ft (10m)
Maximum height of platform
26.2ft (8m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
1.9mph (3Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)
35/40
Minimum turning radius
7.5ft(2.3m)
Gradeability
25%
Overall length
With ladder
8ft (2.42m)
Without ladder
7.4ft (2.25m)
Overall width
3.9ft(1.18m)
Dimension of working platform
(L×W)
7.4ft×3.8ft
(2.26m×1.15m)
Wheel tread
41in(1040mm)
Wheelbase (front/rear)
73in(1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.79in
(100mm/20mm)
Overall height
Rails Folding
5.7ft (1.73m)
Rails un-folding
7.5ft (2.30m)
Overall weight
5203lbs (2360Kg)
Battery
Output Voltage(V)
6
Capacity (AH)
25A/488;75A/132
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
radiation
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3481psi (24MPa)
Tire contact pressure
177.76psi (1225.62KPa)
Ground pressure
217.4psf (10.41KPa)
