2) Lift the safety prop, move it to the center of
the scissor cross tube and rotate it upward
until it is vertical.
3) Lower the platform height until the safety
prop completely contacts the shaft tube.
Keep the platform away from the movable
parts during the lowering process.
△
! Danger
Do not carry any load in the platform
when the safety prop is being used. No
long time (8 hours) to use safety prop in
empty state.
7.13 How to Stow the
Guardrail
.On models SS1230E/SS1432E/SS1932E/
AS1930/AS1930E/AS1932 / AS1932E/
AS2632/AS2632E, the platform guardrail
system consists of a folding guardrail on an
extended platform and a folding guardrail on
the main platform.
1) Fully lower the platform and lock it into the
extended platform.
2) Remove the platform controller.
3) Remove the M-shaped fixed seat between
the guardrails of the main platform and the
extended platform from the inside of the
platform and place it in the platform.
4) Remove the two retaining pins at the front of
the extended platform from the inside of the
main platform.
5) Fold the front guardrail of the extended
platform inward. Do not place your hands in
places where there may be a pinch point. At
the same time, prevent the left and right
guardrails of the extended platform from
tilting over.
6) Install the two retaining pins which were
removed back to the guardrail on each side.
7) Fold the left guardrail of the extending
To Next Page
