LGMG North America Inc.
Operation and Safety Manual
16
is pressed.
3.2.5 Drive/Lift Control Lever
Drive function:
After the enabling switch is pressed, the machine
will move to the forward when the control lever is
moved to the direction (front) indicated by the
blue arrow, or to the backward when the control
lever is moved to the direction (back) indicated by
the yellow arrow.
Lift function:
After the enabling switch is pressed, the platform
will raise when the control lever is moved to the
backward, or lower when the control lever is
moved to the forward.
△
! Notice
When the platform is lowering, the
lowering alarm will beep.
△
! Notice
If using emergency lowering, the alarm
will not beep.
3.2.6 Drive Speed Button
Pressing this button will select the slow or fast
drive function.
3.2.7 Drive Function Button
Pressing this button activates the drive function.
3.2.8 Steer Switch
After the drive function button and the enabling
switch on the lever are pressed, the steer switch
can be used to control the steering direction of
the machine.
3.2.9 Enabling Switch
The driving, steering, lifting or lowering function
can be activated only when the enabling switch
on the lever is pressed.
3.2.10 Indoor or outdoor mode
selection (If equipped)
Via the lift button on the handle for indoor or
outdoor selection (indoor light, outdoor flashing).
When indoor mode is selected, the machine
AS4650/AS4650E can be lifted up to 13.8 m ;
When outdoor mode is selected, the machine can
be lifted up to 8 m and stop lifting.
△
! Warning : In case of indoor mode,
it is prohibited to move the machine
from indoors to outdoors.
