LGMG North America Inc.
Operation and Safety Manual
26
6.13 Operation of Tilt Sensor
Test
△
! Notice
This test is performed with the platform
controller from the ground. Do not
stand in the platform.
1) Completely lower the platform.
2) Drive two wheels on the same side of the
machine up on a 1.37×7.9in (3.5×20cm)
block.
3) Lift up the platform to a height listed in the
following table. Result: The platform will stop
moving and the tilt alarm will sound at a rate
of 120 times per minute.
Table 6- Drive Cutout Height When Tilted
4) Slowly move the control handle to operate
drive forward and then driver reverse. Result:
The drive function will be disabled in either
direction.
5) Lower the platform and drive the machine off
of the blocks.
6.14 Pothole Guard Test
△
! Notice:
When the platform is elevated, the
pothole guards will be automatically
deployed. The pothole guards initialize
another limit switch to enable the
continuous drive/steer operation of
machine. If the pothole guards fails to
be deployed, the alarm will sound and
the machine will stop all drive and steer
functions.
1) Lift the platform. Result: When the platform
elevates a given height (as shown in the
following table), the pothole guards shall be
deployed.
Table 7 - Pothole Deployment Height When Lifting
