LGMG AS3246 User Manual

LGMG North America Inc. Operation and Safety Manual
92
Table 31 - AS3246 Operating Specifications
(Indoor Outdoor)
Item
Parameter
Maximum working height
39.4ft (12m)
Maximum height of platform
32.8ft (10m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
1.9mph (3 Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)）
58/48
Minimum turning radius
7.5ft (2.3m)
Gradeability
25%
Overall length
With ladder
8.1ft (2.47m)
Without ladder
7.4ft (2.25m)
Overall width
3.9ft (1.18m)
Dimension of working platform
(L×W)
7.4ft×3.8ft
(2.26m×1.15m)
Wheelbase (front/rear)
73in (1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.79in
(100mm/20mm)
Overall height
Rails Folding
6.1ft (1.86m)
Rails un-
folding
8ft (2.43m)
Overall weight
6614lbs
(3000Kg)
Battery
Output Voltage(V)
6
Capacity (min)
25A/488;75A/132
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3481psi 24(MPa)
Tire Contact Pressure
163.3psi
1225.62KPa
Ground pressure
247.5psf
11.85KPa
Table 32 – AS4046 Operating Specifications
(In door)
Item
Parameter
Maximum occupant capacity
2
Maximum working height
46ft (14m)
Maximum height of platform
39.4ft (12m)
Extending size of platform
3ft (0.9m)
Maximum allowable working angle
(forward)
3°
Maximum allowable working angle
(backward)
3°
Maximum allowable working angle
(sideward)
1.5°
Max Traveling speed (Stowed)
1.9mph (3Km/h)
Max Traveling speed (Elevated)
0.5mph (0.8Km/h)
Lifting/lowering speed (S)）
65/60
Minimum turning radius (exterior)
7.5ft (2.3m)
Gradeability
25%
Overall length
With ladder
8.1ft (2.47m)
Without ladder
7.4ft (2.25m)
Overall width
3.9ft (1.18m)
Dimension of working platform
(L×W)
7.4ft×3.8ft
(2.26m×1.15m)
Wheelbase (front/rear)
73in(1850mm)
Ground clearance (stowed/lifting
position)
3.94in/0.79in
(100mm/20mm)
Overall height
Rails Folding
6.5ft (1.99m)
Rails un-
folding
8.4ft (2.56m)
Overall weight
6967lbs (3160Kg)
Battery
Output Voltage(V)
12
Capacity (min)
25A/280;75A/70
Charger
Nominal AC Input
Voltage
100-240VAC
Maximum DC Output
Current
30
Nominal DC Output
Voltage
24
Ground environment noise
< 70dBA
Platform environment noise
radiation
< 70dBA
System pressure
3481psi (24MPa)
Tire Contact Pressure
190.98psi
(1316.78KPa)
Ground pressure
280.07psf
(13.41KPa)
