Sensors
SPECIAL FEATURES:
• Automatic measurement of systolic, diastolic and pulse
• 80 measurement results with time & date stored in the device
KEY SPECIFICATIONS
• Measurement method: Oscillometric system
• Measuring range: Pressure 0-300 mmHg
• Pulse 30~200 p/min
• Measuring accuracy: Pressure≤±3 mmHg
• Pulse ≤ 5%
• Operating environment: Temperature 10 - 40ºC
• Relative humidity ≤ 80%
The sensor needs to be connected to the specic Blood Pressure Monitor jack connector in MySignals board and
it works with internal rechargeable battery. Use the Blood pressure specic cable in order to charge the sensor
connected to MySignals.
Figure: Blood Pressure sensor with charger cable connected
Measurement:
Parameter Unit Range
Systolic pressure mm Hg 0-300 mmHg
Diastolic pressure mm Hg 0-300 mmHg
Pulse ppm 30~200 ppm
