Sensors
Figure: EMG electrodes removing protective plastic
This sensor use disposable pre-gelled electrodes.
These high quality disposable electrodes are to be used to measure EEG, ECG and EMG. They are to be used once
and are very handy because of integrated gel. They adhere very well to the skin and are clean to use.
The H124SG has a unique, patented pre-gelled adhesive side with non-irritating gel, especially developed to
prevent allergic reactions. These foam electrode is latex free and therefore suitable for every skin type.
The snap-on connector can easily be pushed on or removed from the electrode lead.
Place the electrodes as shown below.
Figure: EMG position diagram
After a few seconds you will get the values in the visualization method programmed.
NOTE: It is recommended not use this sensor in environments with excessive electromagnetic noise.
