Sensors
Connect the jack sensor in the ECG connector indicated in the MySignals Hardware board. The sensor cable have
only one way of connection to prevent errors and make the connection easier.
Figure: MySignals Hardware Development Platform with ECG connected
Connect the ECG lead to the electrodes.
Figure: ECG connecting ECG electrodes
NOTE: Connect the ECG Electrodes to the ECG sensor before placing them in the user body.
