Liebert CRV+ Series User Manual

40 Chapter 5 Micro-Processing Controller
Liebert CRV+ Series Air Conditioner User Manual
Teamwork Set
The Teamwork Set screen is shown in Figure 5-32.
Figure 5-32 Teamwork Set menu
Manual Mode
The Manual Mode screen is shown in Figure 5-33. If YES is selected for Manual Ena, the output can be manually
controlled. For example, set Fan Speed to 75%, and set Fan Output to ON, the fan will operate at 75% output.
Before setting Comp Output, Heat Output and Humd Output, you need to turn on the fan first. Soft Off and Lquid
Valve are linked with the compressor state, only for viewing, and cannot be manually controlled. You must quit the
manual mode manually.
Soft Off NO
Comp Output ON
Vacucm State NO
Lquid Valve OFF
Figure 5-33 Manual Mode menu
 Note
1. It is recommended not to operate the Manual Mode by the user, if necessary, please operate it by professional personnel.
2. You must quit the manual mode manually.
Sel Option
The Sel Option screen is shown in Figure 5-34. The parameters of remote temperature adjustment will not be
cleared upon power-off. For detailed setting ranges, refer to Appendix 4 Parameter Setting Table.
Figure 5-34 Sel Option menu
5.6.6 Help Menu
Select Help Menu on Main Menu screen to enter the screen shown in Figure 5-35. Enab 1st Run is not open to the
user and cannot be viewed.

Liebert CRV+ Series Specifications

General

Refrigerant	R410A
Frequency	50/60 Hz
Operating Ambient Temperature	64° to 113°F (18° to 45°C)
Sound Pressure Level	Varies by model (typically 45 dB(A) to 65 dB(A))
Dimensions	Varies by model (consult specific model documentation)
Weight	Varies by model (consult specific model documentation)
