Liebert CRV+ Series User Manual

38 Chapter 5 Micro-Processing Controller
Liebert CRV+ Series Air Conditioner User Manual
Figure 5-25 On/Off Record menu
Select ‘Fan’ on the On/Off Record screen to query the start and stop records of fan, including XX/YY, fan start time,
fan stop time, as shown in Figure 5-26. XX is the serial number of the start and stop record and YY is the total
number of start and stop records. The start and stop records of other components are similar.
Figure 5-26 Fan On/Off Record menu
5.6.5 System Set
Select System Set on Main Menu screen to enter the screen shown in Figure 5-27. The parameters of System Set
will not be cleared upon power-off.
<Fan Set>
<Comp Set>
<EEV Set>
<Common Set>
Figure 5-27 System Set menu
Common Set
The Common Set screen is shown in Figure 5-28. For detailed setting ranges, refer to Appendix 4 Parameter
Setting Table.
Figure 5-28 Common Set menu
Restore factory
On the Common Set screen, press the Up or Down button to move the cursor to Rst Facty and press the Enter
button, then press the Up or Down button to select YES or NO, and press the Enter button to confirm it. If YES is

Liebert CRV+ Series Specifications

General

Refrigerant	R410A
Frequency	50/60 Hz
Operating Ambient Temperature	64° to 113°F (18° to 45°C)
Sound Pressure Level	Varies by model (typically 45 dB(A) to 65 dB(A))
Dimensions	Varies by model (consult specific model documentation)
Weight	Varies by model (consult specific model documentation)
