Liebert Hisp - Page 86

11
Fig. 6 --- Electrical connections --- Collegamenti ele ttric i
SCcontrol/ControllounitàSC
AC power supply / alimentazione elettrica AC
Microface display / Display Microface
AC
(optional)
DC
DC power supply (optional) / alimentazione elettrica DC (opzionale)
F i g . 7 --- E l e c t r i c a l d i a g r a m S E + S C 0 5 --- 0 6 --- S c h e m a e l e t t r i c o S E + S C 0 5 --- 0 6
TO BE DONE BY INSTALLER
OPTIONAL HIROSS WITH ALLARM BOARD
OPZIONALE HIROSS CON SCHEDA ALLARMI
MAIN SUPPLY 230Vac
EMERGENCY SUPPLY 24/48Vdc
OR Ext. INVERTER 230Vac (optional)
FASTON 6,3 mm
A CURA DELL’INSTALLATORE
TO BE DONE BY INSTALLER
A CURA DELL’INSTALLATORE
OPTIONAL--OPZIONALI
2
PE
SHIELDED CABLE 7X1 mm2
CAVO SCHERMATO 7X1 mm2
SHIELDED CABLE 2X1 mm2
CAVO SCHERMATO 2X1 mm2
SHIELDED CABLE 2X1 mm2
CAVO SCHERMATO 2X1 mm2
TO MICROFACE
TO DI SPLAY
PE
57 55
56
057
N6
U2
PE
400 402
300
301
302
34
35
64
65
401
CAVO HIROBUS 8 POLI SCHERMATO COD.275635
SHIELDED HIROBUS CABLE 8 POLES COD.275635
CAVO 4+PE 2.5 mm
CABLE4+PE2.5mm
2
CAVO SCHERMATO 4X1.5 mm
2
SPLIT UNIT -- SE.. + SC.. ELECTRICAL CONNECTIONS
2
PE
57 55 057
56
U2N6
402
34
35
64
65
401
400 302
301
300
SHIELDED CABLE 4X1.5 mm
020 1
SHIELDED CABLE 2X1 mm2
CAVO SCHERMATO 2X1 mm2
020
1
FASTON 6,3 mm
SHIELDED CABLE 3X1 mm2
CAVO SCHERMATO 3X1 mm2
G0 G 70
G
70
G
G0
G0 Y2
R1 R2 C2 R3 C3 R4 R5 C1
ON OFF
FASTON 6,3 mm
ON/OFF
REMOTE SWITCH
SCHEDA ALLARMI (OPZIONALE)
ALLARM BOARD (OPTIONAL)
U6
U6
N2
N2
